Cat. No. 09421

Microphones | Dynamic Microphone

General Description

The cardioid e 935 is a fully professional vocal microphone, developed to cut

through high on-stage levels.

Features

Rugged metal body

Advanced shock-mount design

Consistent on-/off-axis response

Hum compensating coil

Delivery includes a pouch and a microphone clamp

Technical Data

Pick-up pattern ...................................................................... cardioid

Frequency response .................................................40 – 18,000 Hz

Sensitivity

(free field, no load, 1 kHz)...........................2.8 mV/Pa at 1 kHz =

-51 dB (0 dB = 1V/Pa)

Nominal impedance ................................................................. 350 Ω

Min. terminating impedance..................................................... 1 kΩ

Dimensions ....................................................................47 x 181 mm

Weight ........................................................................................ 330 g

Profile

Cardioid professional vocal microphone, hum compensating

coil, frequency response 40 – 18,000 Hz, sensitivity (free field,

no load) 2.8 mV/Pa at 1 kHz = -51 dB (0 dB = 1V/Pa), nominal

impedance 350 Ω, min. terminating impedance 1 kΩ, dimen-

sions 47 x 181 mm, weight 330 g.

Cat. No. 09421 1
